Plan TD-44090-2 -3: Two-story 3 Bed Modern ICF House Plan With Home Office

Page has been viewed 815 times

TD-44090-2 -3

House Plan TD-44090-2 -3

Mirror reverse
  • One of several similar designs in this series, this modern home plan is modelled after the opulent beach homes of the Caribbean coast.
  • It features a modern kitchen that serves as both a dining area and an eating bar.
  • The master bath is well-lit and opens to the private outdoor garden.
  • The Great Room has a two-story ceiling and a modern stair leading to the upper floor with two bedrooms, an office, and a bath.
  • It also opens to a rooftop observation deck with glass railings.

Total Square: 2450 sq.ft

Width: 60′0″

Depth: 64′12″

Floors: 2

Bedrooms: 3

Bathrooms: 3

Garage Bays: 2

REAR VIEW

Фото 4

REAR VIEW

Фото 2

THE GREAT ROOM

Визуализация кухни TD-44090-2-3

THE KITCHEN

Кухня

Convert Feet and inches to meters and vice versa

ft   in=m

Only plan: $325 USD.

Additional Options: + $980 USD.
+ $650 USD.
+ $650 USD.
*Small changes in plan included.
Total:

HOUSE PLAN INFORMATION

Quantity

Floor
2
Bedroom
3
Bath
3
Cars
2
Half bath
1

Dimensions

Total heating area
2450 sq.ftsquare
1st floor square
1760 sq.ftsquare
2nd floor square
690 sq.ftsquare
House width
60′0″
House depth
64′12″
Ridge Height
25′11″
1st Floor ceiling height
9′10″
2nd Floor ceiling height
8′10″
Building construction type
Concrete block house plansICF house plans (concrete)



Foundation
  • slab
  • crawlspace



Walls

Exterior wall thickness
200
Wall insulation
7 BTU/h
Facade cladding
  • stucco
  • horizontal siding
  • facade panels



Main roof pitch
0 by 12
Roof type
a flat roof



Rafters
  • wood trusses



Living room feature
  • fireplace
  • open layout



Kitchen feature
  • kitchen island
  • pantry



House Plans with Fireplace
Bedroom Feature
  • walk-in closet
  • 1st floor master
  • outdoor exit
  • bath and shower



Special rooms
House plans with home officeFirst floor master bedroom house plans



Garage type
Attached garage house plans



Garage Location
Front
Garage area
520 sq.ftsquare
Outdoor living
second story deckpatio



Plan shape
  • U-shaped



Style
Contemporary



Suitable for
a towna view lotfor a country house



Features

Client's photos
