Plan DA-72565-1-3: One-story 3 Bed Chalet Style House Plan

Page has been viewed 665 times

photo_title

House Plan DA-72565-1-3

Mirror reverse

A one-story house plan is up to 200 sqm with a garage for 2 cars and 3 bedrooms with a typical American layout and large covered terraces in front and behind.

The house is rectangular in plan and consists of three parts. In the central part of the house, there is a common large square room with windows facing forward and backward to the terraces. This room combines a living room, dining room, and kitchen. The kitchen is located at the back and has a corner kitchen island.

The sleeping quarters are located on the left-wing of the house, while the garage and utility rooms are on the right-wing.

Total Square: 2138 sq.ft

Width: 85′11″

Depth: 56′1″

Floors: 1

Bedrooms: 3

Bathrooms: 3

Garage Bays: 2

Convert Feet and inches to meters and vice versa

ft   in=m

Only plan: $250 USD.

Additional Options: + $750 USD.
+ $500 USD.
+ $500 USD.
*Small changes in plan included.
Total:

HOUSE PLAN INFORMATION

Quantity

Floor
1
Bedroom
3
Bath
3
Cars
2
Half bath
1

Dimensions

Total heating area
2140 sq.ft
1st floor square
2140 sq.ft
House width
85′11″
House depth
56′1″
Ridge Height
21′4″
1st Floor ceiling height
8′10″
Building construction type



Foundation
  • crawlspace



Walls

Exterior wall thickness
2x6
Wall insulation
11 BTU/h
Main roof pitch
5 by 12
Rafters
  • lumber



Living room feature
  • fireplace
  • open layout



Kitchen feature
  • pantry



Bedroom Feature
  • walk-in closet
  • 1st floor master



Garage Location
front
Garage area
600 sq.ft
Style



Features

Client's photos
