Modern House Plan With Shed Roof, 2 Car Garage and 3 Bedrooms

Page has been viewed 901 times

PM-80913-1-3

House Plan PM-80913-1-3

Mirror reverse

This floor plan of a modern 3 bedroom home with an impressive pitched roof is filled with natural light. The contrasting elements of the façade, the covered entrance, and the garage for 2 cars give the house a great appeal.
Just behind the foyer, there is a living room combined with a dining room and kitchen. The huge kitchen island is great for cooking and is just steps from the pantry.
Sliding doors from the kitchen lead to the patio.
The bright master bedroom is equipped with a bathroom and a dressing room. Two additional bedrooms are on the first floor.
From the garage for 2 cars, you can go through the entrance hall with a wardrobe to the living room.

Total Square: 1887 sq.ft

Width: 49′10″

Depth: 56′1″

Floors: 1

Bedrooms: 3

Bathrooms:

Garage Bays: 2

HOUSE LEFT ELAVATION

Передний фасад. План PM-80913-1-3

LEFT ELEVATION

Левый фасад PM-80913-1-3

REAR ELEVATION

Задний фасад. План PM-80913-1-3

RIGHT ELEVATION

Правый фасад. Проект PM-80913-1-3

Convert Feet and inches to meters and vice versa

ft   in=m

Only plan: $225 USD.

Additional Options: + $680 USD.
+ $450 USD.
+ $450 USD.
*Small changes in plan included.
Total:

HOUSE PLAN INFORMATION

Quantity

Floor
1
Bedroom
3
Bath
Cars
2

Dimensions

Total heating area
1890 sq.ftsquare
1st floor square
1890 sq.ftsquare
Basement square
1890 sq.ftsquare
House width
49′10″
House depth
56′1″
Ridge Height
23′11″
1st Floor ceiling height
7′10″
Foundation



Walls

Exterior wall thickness
2x6
Wall insulation
11 BTU/h
Facade cladding
  • horizontal siding
  • wood boarding



Main roof pitch
41 by 12
Roof type
a shed roof



Rafters
  • wood trusses



Living room feature
  • open layout



Kitchen feature
  • kitchen island
  • pantry



Bedroom Feature
  • walk-in closet
  • 1st floor master



Garage type
House plans with built-in garageAttached garage house plans



Garage Location
front
Garage area
530 sq.ftsquare
Style
Contemporary



Suitable for
a towna small lota young family
