Plan GS-3112-1-2: One-story House Plan For Narrow Lot

Page has been viewed 403 times

GS-3112-1-2

House Plan GS-3112-1-2

Mirror reverse

The hunting lodge was designed for cold climates. The loft can sleep two people. This project is ideal for mounting solar panels on the roof as well as collecting rain and melting water. The design of the house also includes a system for generating electricity from the solar panel as well as a complete list of building materials. A strip foundation with a sub-floor and herringbone siding is standard with this project. An additional option is wood chips or cedar wood siding. Exterior walls are built of 50x150 mm boards with insulation made of polyurethane foam, providing increased heat resistance. The roof is made of 50x300 boards and insulated with 230 mm-thick sprayed polyurethane foam. The roof can be covered with asphalt shingles or metal tiles.

Total Square: 63.3 sq.m

Width: 9 m

Depth: 7.2 m

Floors: 1

Bedrooms: 1

Bathrooms: 1

Garage Bays: none

Вид справа

Convert Feet and inches to meters and vice versa

ft   in= m

Only plan: $100 USD.

Additional Options: + $300 USD.
+ $200 USD.
+ $200 USD.
*Small changes in plan included.
Total:

HOUSE PLAN INFORMATION

Quantity

Floor
1
Bedroom
1
Bath
1
Cars
none

Dimensions

Total heating area
63.3 m2
House width
9 m
House depth
7.2 m
1st Floor ceiling height
2.7 m
Building construction type
Wood frame house plans



Foundation
  • slab
  • crawlspace



Walls

Exterior wall thickness
0.15
Wall insulation
5 Wt(m2 h)
Main roof pitch
34°
Roof type
a gable roof



Rafters
  • lumber



Living room feature
  • fireplace
  • open layout



Suitable for
a vacation retreatcold climates
